Strip Steel Thickness 0.15-1.0mm
Strip Steel Width 700-1250mm
Coil Inner Diameter φ508/φ610
Coil Outer Diameter Max.φ1500mm Min φ800mm
Coil Weight MAX.10t
Maximum Process Speed 180m/min
Galvanized Coat Thickness 15-100g/m²(GL)
Product Level SQ/CQ/DQ/HSLA
Surface Treatment common chromating
The annual output 1.1million tons continuous hot galvanizing 5-line unit adopts total radiation tube heating horizontal furnace,adopts ceramics
inductor heating zinc pot equipped with special-purpose air knife. The outlet is equipped with finishing tension leveler.
